Register Your Own MCP Server

Any MCP server that speaks streamable HTTP can be registered in Brutor. Once registered and assigned to a resource group, every portal user and agent in that group can call it through /v1/proxy/mcp/{server_id} — with tool filters, guardrails, approvals, and audit applied by the gateway, not by your server.

This walkthrough uses the pattern from brutor-weather-mcp-server: a single-tool server small enough to read in one sitting.

1. Build a minimal FastMCP server

weather_server.py

import os
import httpx
from mcp.server.fastmcp import FastMCP

HOST = os.getenv("MCP_HOST", "0.0.0.0")
PORT = int(os.getenv("MCP_PORT", "3012"))

mcp = FastMCP(name="weather-assistant", host=HOST, port=PORT)

@mcp.tool()
async def get_current_weather(city: str) -> str:
    """Gets the current weather in a given location.
    Geocodes the city, then fetches current conditions from Open-Meteo.

    Args:
        city: Location of interest (city name)
    """
    async with httpx.AsyncClient() as client:
        geo = await client.get(
            "https://nominatim.openstreetmap.org/search",
            params={"q": city, "format": "json", "limit": 1},
            headers={"User-Agent": "MCP Weather Assistant"},
        )
        geo.raise_for_status()
        results = geo.json()
        if not results:
            return f"Could not find location data for '{city}'."
        lat, lon = float(results[0]["lat"]), float(results[0]["lon"])

        wx = await client.get(
            "https://api.open-meteo.com/v1/forecast",
            params={"latitude": lat, "longitude": lon, "current_weather": True},
        )
        wx.raise_for_status()
        current = wx.json().get("current_weather", {})
        return (
            f"Weather for {results[0]['display_name']}: "
            f"{current.get('temperature', 'N/A')}°C, "
            f"wind {current.get('windspeed', 'N/A')} km/h"
        )

if __name__ == "__main__":
    # FastMCP serves the MCP protocol at the /mcp path
    mcp.run(transport="streamable-http")

pip install "mcp[cli]" httpx
python weather_server.py
# → MCP server available at http://0.0.0.0:3012 (protocol endpoint: /mcp)

FastMCP’s streamable-HTTP transport serves the protocol at the /mcp path — the connectable URL is http://localhost:3012/mcp. The tool’s docstring and type hints become the MCP tool description and input schema automatically.

Smoke-test it directly

Streamable-HTTP MCP is stateful — every call after initialize must carry the Mcp-Session-Id the server returns. A bare tools/list gets Bad Request: Missing session ID.

# 1. Initialize — grab the session id from the response headers
curl -s -D - -X POST http://localhost:3012/mcp \
  -H "Content-Type: application/json" \
  -H "Accept: application/json, text/event-stream" \
  -d '{"jsonrpc":"2.0","id":1,"method":"initialize","params":{
        "protocolVersion":"2025-06-18",
        "clientInfo":{"name":"curl-smoke","version":"1.0"},
        "capabilities":{}}}'
# → mcp-session-id: 0b0cfcef9f2d4aa3920482a49441da22

# 2. List tools with the session id
curl -s -X POST http://localhost:3012/mcp \
  -H "Content-Type: application/json" \
  -H "Accept: application/json, text/event-stream" \
  -H "Mcp-Session-Id: 0b0cfcef9f2d4aa3920482a49441da22" \
  -d '{"jsonrpc":"2.0","id":2,"method":"tools/list","params":{}}'

event: message
data: {"jsonrpc":"2.0","id":2,"result":{"tools":[{"name":"get_current_weather","description":"Gets the current weather...","inputSchema":{"properties":{"city":{"title":"City","type":"string"}},"required":["city"],"type":"object"}}]}}

Reachability from Docker

If the gateway runs in the trial-bundle Docker Compose and your server runs on the host, register it as http://host.docker.internal:3012 — localhost inside the gateway container is the container, not your machine. On a shared network, use the host’s LAN IP.

2. Register it in Brutor

1. Admin UI (recommended): Resources → MCP Servers → Configuration → Add. Set Base URL http://host.docker.internal:3012, MCP endpoint path /mcp, Auth type None (this server has no auth of its own — the gateway is where access control lives). Use Test Connection before saving; capability discovery runs automatically on create — and records which MCP protocol version and wire dialect (handshake or stateless 2026-07-28) your server negotiated, so the gateway speaks your server’s own dialect from then on.

2. Or via the Admin API (Control Plane, :5050 — login first, see setup scripts):

   curl -s -X POST http://localhost:5050/v1/admin/mcp-servers \
     -H "Authorization: Bearer $ADMIN_TOKEN" \
     -H "Content-Type: application/json" \
     -d '{
       "name": "Weather Assistant",
       "description": "Demo weather tool (Open-Meteo)",
       "base_url": "http://host.docker.internal:3012",
       "mcp_endpoint_path": "/mcp",
       "auth_type": "none",
       "timeout": 30.0,
       "enabled": true
     }'

   The response includes the generated server id — mcp-01ARZ3NDEKTSV4RRFFQ69G5FAV — which is also the path segment of the governed endpoint. Registration is idempotent by base_url + mcp_endpoint_path: a duplicate returns 409.

   Useful maintenance endpoints:

   Endpoint	Purpose
   POST /v1/admin/mcp-servers/test-connection	Probe a URL (with OAuth/OIDC discovery) before creating
   POST /v1/admin/mcp-servers/{id}/refresh-capabilities	Re-discover tools/resources/prompts after you add a tool
   POST /v1/admin/mcp-servers/{id}/health-check	On-demand health probe (the gateway also health-checks periodically)
   POST /v1/admin/mcp-servers/{id}/icon	Upload an icon (multipart) shown in the portal’s server picker

3. Assign it to a resource group. Access is granted through a server configuration — the object the portal and agents discover servers by:

   curl -s -X POST http://localhost:5050/v1/admin/server-configs \
     -H "Authorization: Bearer $ADMIN_TOKEN" \
     -H "Content-Type: application/json" \
     -d '{
       "name": "Weather (Sales workspace)",
       "mcp_server_id": "mcp-01ARZ3NDEKTSV4RRFFQ69G5FAV",
       "group_ids": ["rg-01ABC..."],
       "display_name": "Weather",
       "enabled": true
     }'

   In the Admin UI this is the server’s Access tab. From here you can also set per-group tool filters (enable/disable individual tools) and approval requirements — see Resource Groups.

3. Call it through the gateway

Same JSON-RPC as the direct smoke test, but now against the governed endpoint with an API key from the resource group:

curl -s -X POST http://localhost:8100/v1/proxy/mcp/mcp-01ARZ3NDEKTSV4RRFFQ69G5FAV \
  -H "Authorization: Bearer sk_brutor_api_..." \
  -H "Content-Type: application/json" \
  -H "Accept: application/json, text/event-stream" \
  -H "Mcp-Session-Id: 0b0cfcef9f2d4aa3920482a49441da22" \
  -d '{"jsonrpc":"2.0","id":3,"method":"tools/call",
       "params":{"name":"get_current_weather","arguments":{"city":"Berlin"}}}'

event: message
data: {"jsonrpc":"2.0","id":3,"result":{"content":[{"type":"text","text":"Weather for Berlin, Deutschland: 21.4°C, wind 11.2 km/h"}]}}

Success moment: open Mission Control → Traffic (or Monitoring → Proxy Logs) and find the tools/call row — caller, server, capability name, latency, and the argument preview are all there.

Then try it from the User Portal: log in as a user in the same resource group, ask a chat “what’s the weather in Berlin?” — the model discovers get_current_weather and calls it through the gateway.

What the gateway now enforces for you

Your 60-line server gained, with zero code in it:

• Access control — only credentials in the assigned resource group(s) can reach it; per-tool enable/disable per group
• Approvals — mark a tool “requires approval” and calls pause for a human (Approvals)
• Guardrails — mcp_input checks on arguments, mcp_output checks (e.g. PII redaction) on results (Guardrails)
• Health checks — periodic probes; unhealthy servers are flagged in the Admin UI and portal
• Audit + metering — every call logged and attributed

Don't expose the bare server

The demo server has no authentication by design — anyone who can reach port 3012 can call it. Keep it on a private network reachable only by the gateway; the gateway endpoint is the public face. For defence in depth, set auth_type: "bearer" (static token) or oauth on registration.
